Russound D1650, 16-Channel AMP 50W Digital Amplifier
• Independent gain adjustment for each channel allows volume fine tuning and maximum volume level settings for each zone
• Stereo RCA global bus input for distributing a single audio source among multiple amplifier channels of your choice
• Protection circuit provides safe and reliable operation for each amplifier output channel under extreme conditions
• Cascade bus input/output for "daisy-chaining" additional amplifiers
• Audio signal sensing with auto-switching delay settings per zone
• Detachable speaker terminals support up to 14-gauge wire
• 16-channel amplifier with 8 independent playback zones
• High-efficiency, cool running Class D amplification
• Rack mountable chassis (rack mount ears included)
• Independent trigger input/output for each zone
• 8 stereo RCA audio inputs, one for each zone
• Global trigger input/output
• Removable AC power cord
• Power Requirement(s) ~ International Model (D850i):
220-240VAC 50Hz 600W max
IEC C14 type connector with 3 terminal detachable power cords for UK, Europe, and Australia
• Power Requirement(s) ~ North American Model:
100-120VAC 60Hz 600W max
IEC C14 type connector with 3 terminal detachable power cord
• Speaker Connection(s) ~ Detachable speaker terminals support up to 14awg wire
• Fuse Rating ~ 100-120V/T5A, 250V US & Canada, 220-240V/T2.5A, 250V Europe
• Frequency Response ~ 20Hz to 20kHz +1.7/-1dB at 1W output into 8 Ohms
• Switching Delay ~ Three settings, 5 Seconds, 5 minutes, 10 minutes
• Bridge Mode ~ Select Stereo or Bridge mode per zone 8 Ohm only
• Power Output ~ 80W /Channel, 1kHz into 4 Ohms, One Zone Driven
• Power Output ~ 50W /Channel, 1kHz into 8 Ohms, One Zone Driven
• Input Sensitivity ~ 600 mV for 80W @ 1 KHz 4 Ohm One Zone
• Input Sensitivity ~ 700 mV for 50W @ 1 KHz 8 Ohm One Zone
• Amplifier Channels ~ 16 Channels, 8 independent zones
• Zone Line Input ~ Line or Bus select switch per zone
• Power Output ~ 160W, 1kHz into 8 ohms, Bridge
• Dimensions (W x H x D) ~ 21.5" x 9.0" x 22.0"
• Signal to Noise Ratio ~ >90dB A-weighted
• Input Impedance ~ >22k Ohms Line Input
• Trigger Input(s) ~ Bus and Zone @12VDC
• Shipping Weight ~ 28.8 lbs
In the Box
• Pre-installed 2 Rack-mount brackets
• 6 foot AC power cord
